A Simple Technique of Inserting an Intra-Abdominal Drain


in Laparoscopic Surgery



Vishwanath Golash


  OMJ  JAN  2009  VOL.24   NO.1  P.7  doi:10.5001/omj.2009.3


Objectives: We describe a simple technique for introducing any size of intra-abdominal drain in laparoscopy through a 3-5 mm port site without any of the drawbacks of other techniques practised.

Methods: Setting is usually of a conventional laparoscopic surgery with various ports positioned depending on the procedure performed. At the end of theprocedure a 5 mm port site cannula is usually chosen to ‘pull in’ an intra-abdominal drain by railroading, under vision.

Results: Railroading method of insertion of intra-abdominal drain in laparoscopy is always successful with no failure rate and no associated complications.

Conclusion: When indicated, this is the simplest method of inserting an intra-abdominal drain after laparoscopic surgery.


From the Department of  Surgery, Sultan Qaboos Hospital, Post Box: 98, Salalah, Postal Code: 211, Sultanate of Oman.

Received: 14 Sept 2008

Accepted:  23 Nov 2008

Address correspondence and reprint to: Vishwanath Golash, Department of Surgery, Sultan Qaboos Hospital, P.O. Box: 98, Salalah, Postal Code: 211, Sultanate of Oman

E-mail: golash@omantel.net.om  and haritagolash@hotmail.com


Laparoscopic insertions of intra-abdominal drains have multiple indications. Closed suction drains are used routinely to drain potential collections after surgery or after bowel anastomosis. The primary operation alone for peritonitis may be inadequate for severe forms of peritonitis and drains are frequently required in primary, secondary and tertiary peritonitis.1 In high-risk cases of duodenal ulcer perforation and perforated diverticular disease where definitive surgery is not possible, laparoscopic insertion of an intra-abdominal drain alone may be life-saving.2,3 CT/US-guided drainage of intra-abdominal abscesses is becoming a standard but when expertise is not available a drain can safely be introduced under vision to drain the abscess with laparoscopic guidance.4 Laparoscopic insertion of drains has also been used in the treatment of postoperative complications after open abdominal procedures.5,6 The access to the abdominal cavity and intra-abdominal spaces is better achieved with laparoscopy. An intra-abdominal drain is sometimes inserted for the removal of any residual fluid and collection in cases of peritonitis and in suspected leaks. Inserting an intra-abdominal drain is sometimes cumbersome through the port sites. There are several techniques for inserting an intra-abdominal drain in laparoscopy. Usually the entire drain tube is threaded into the intra-abdominal cavity through the port and the distal end of the tube positioned at the desired location. In another method the proximal end of the tube is threaded through a first port and out through a second access port to draw the distal end of the tube into the intra-abdominal cavity. But these techniques have the drawbacks of gas leak and only a small size drain can be threaded through a 3-5 mm port unless a 10 mm port site is used (which is not recommended).7,8,9 With the technique described below, any size of drain can be inserted through a 3-5 mm port site without any of the drawbacks of other techniques mentioned.


Between June 1998 and July 2007, a total of 5,900 laparoscopic procedures were performed in our hospital. Retrospective data were retrieved from the surgery logbook. The main indications for intra-abdominal drains were peritonitis, bowel and biliary anastomosis, biliary surgery, gastric resection, bowel injury, pelvic surgery, various types of laparoscopic hernia surgeries and concomitant laparoscopic procedures. Laparoscopic-guided drainage and drain insertion were also performed in liver abscesses, intra-peritoneal abscesses, and retroperitoneal abscesses, postoperative intra-peritoneal collection following laparotomy, laparoscopy and abdominal trauma. The intra-peritoneal drains were frequently used in the learning curve of laparoscopy. Several techniques of drain insertion were tried but with increasing experience we found a simpler technique for drain insertion as follows:

Intra-operative technique: A 5 mm port cannula and the tip of grasper (inserted through another port) were aligned together. The grasper was threaded inside the lumen of the 5 mm cannula as shown (Figure 1). The grasper was snugly accommodated further inside the port. By railroading, the 5 mm cannula was gradually withdrawn while still holding the grasper blades inside the cannula. The closed grasper jaws were brought out through the 5 mm port site and the 5 mm cannula removed (Figure 2). The distal end of the drain (Evacuator Barovac, closed wound drainage system, outer diameter varying from medium 3.2 mm to extra large
6.4 mm) was threaded over one of the open jaws of the grasper. To prevent gas leak, the proximal trocar end of the drain was not cut (Figure 3). The drain usually snugly fits in the port site without any gas leak. While holding the drain in the closed grasper, the drain was gently pulled into the intra-abdominal cavity by withdrawing the grasper under vision. The drain was positioned in the desired location (Figure 4).


Figure 1: Threading grasper


Figure 2: Railroading grasper


Figure 3: Proximal uncut trocar end


Figure 4: Drain pulled intra-abdominally


Intra-abdominal drains were used in 17% (996 cases) of the laparoscopic surgery (The 95% confidence interval extends from 0.089 to 0.186). Drain size varied from 3.2 to 5 mm and the mean duration of drain was two days (range one to days) depending on indications. Drains were used routinely in all cases of peritonitis and selectively in other surgeries. For the last few years we have used drains in all cases of laparoscopic repair of ventral hernia to reduce the incidence of seroma formation. Right lower abdomen was the most preferred site for drain insertion using a 5 mm port cannula. We succeeded in inserting an intraabdominal drain by this technique in all cases without any difficulty. There were no drain-related complications and no case of port site hernia at drain site in follow up varying from six months to nine years.


Table 1: Indications for Intraabdominal Drain in Laparoscopic surgery in 996 patients in our unit


Number of patients

Appendicitis with peritonitis


Perforated peptic ulcer


Perforated diverticular disease


Biliary anastomosis (choledochoduodenostomy)


Bowel anastomosis (Hartmann reversal etc.)


Biliary surgery (postcholecystectomy)


Gastric resections and anastomosis


Bowel injury


Pelvic surgery


Ventral hernia repair


Inguinal hernia repair


Concomitant & complicated laparoscopic surgery


Liver abscess


Intraperitoneal abscess


Retroperitoneal abscess


Postoperative intraabdominal collection


Abdominal trauma




Depending on the surgeon’s choice and the surgical procedure, an intra-abdominal drain may be required to drain the surgical site. They have been used for prophylactic, diagnostic and therapeutic purposes.10-14 Drains may be advisable in routine surgery to drain postoperative collection, bleeding, in peritonitis and bowel anastomosis. Laparoscopy is very effective in thorough suction and irrigation of the peritoneal cavity and accurate placement of the drain under vision. Usually the smallest size port entry is used to avoid future complications of port site hernia and obstruction.15 Only one grasper is required and a 5 mm port site is usually adequate even for larger drains. All of the techniques described for the insertion of intra-abdominal drains have drawbacks. In the common technique of direct introduction of drain through the port, the pressurization gas escapes from the abdominal cavity through the drain tube itself and through the port while the drain tube is being threaded. Secondly, only a small sized drain tube can be threaded through a 3 or 5 mm port. In another technique of threading through a first port and out through a second access port to draw the distal end of the tube intra-peritoneally, the jaws of the grasper are expanded to a width with the drain tube there between, such that the surgical instrument cannot be withdrawn through the operating port. This results in a struggle to pull the drain out and gas leak, unless a very small caliber drain is used. These techniques make the introduction of the drain cumbersome. Our technique has rectified these drawbacks.


We believe this is a simple technique for introducing an intra-abdominal drain in laparoscopic surgery.


The author report no conflict of interest and no funding has been received in this work.

  1. Wittmann DH, Schein M, Condon RE. Management of Secondary Peritonitis. Annals of Surgery 1996; 224:10-18.

  2. Urbano D, Rossi M, DeSimone P, Berloco P, Alfani D, Cortesini R. Alternative laparoscopic management of perforated peptic ulcers. Surg. Endosc 1994; 8:1208-1211.

  3. Faranda C, Barrat C, Catheline, J, Champault G G. Two-stage laparoscopic management of generalized peritonitis due to perforated sigmoid diverticula: eighteen cases. Surgical laparoscopy, endoscopy & percutaneous techniques 2000; 10:135-138.

  4. Kok KYY, Yapp SKS. Laparoscopic drainage of postoperative complicated intra-abdominal abscesses. Surgical laparoscopy, endoscopy & percutaneous techniques. 2000; 10:311-313.

  5. Nassar AHM, Htwe T, Hefny H, Kholeif Y. The abdominal drain a convenient port for second-look laparoscopy. Surg Endosc 1996; 10:1114-1115.

  6. Singh K, Lamparelli M, Foley RJE, Use of a laparoscopic trocar for percutaneous introduction of drains into intra-abdominal abscesses, British journal of Surgery 1996; 83:670-671.

  7. Dutro JA, Bernie WA, Mckellar D. Technique of Drain Placement during Operative Laparoscopy. Journal of Laparoendoscopic Surgery 1991; 1:225-226.

  8. Reissman P, Cohen SM, Weiss EG, Wexner SD. Simple technique for pelvic drain placement in laparoscopic abdominoperineal resection. Diseases of colon and rectum. 1994, 37:381-382.

  9. Haq A,Ribeiro B, Cook L.Further modification of technique for laparoscopic placement of drain following cholecystectomy. Surgical Endoscopy 2007; 21:691-692.

  10. Thomson BNJ, Cullinan MJ, Banting SW, Collier NA. Recognition and management of biliary complications after laparoscopic cholecystectomy. ANZ; 2003; 73:183-188.

  11. Daniloś J, Paluszkiewicz P, Przesmycki K, Kotarski J. Successful treatment with recombinant factor viia for intractable bleeding at pelvic surgery. Obstetrics & Gynecology 2003; 101:1172-1173.

  12. Oh ST, Kim WS, Kim BS. Changing patterns of pancreatic enzyme after distal gastrectomy and the effect of protease inhibitor treatment. J Korean Surg Soc 1997; 52:846-851.

  13. Amit Shah: Postoperative peritonitis. The Internet Journal of Surgery. 2005. Volume 6 Number 2.

  14. Memon M A, Memon B, Memon M I, Donohue JH. The uses and abuses of drains in abdominal surgery. Hospital Medicine. 2002; 63:282-288.

  15. Palanivelu C, Rangarajan M, Senthilkumar R, John S, Madankumar M V. Laparoscopic management of drain-site incisional hernias following laparotomies-A simple suture technique. Journal of Laparoendoscopic & Advanced Surgical Techniques 2007; 17:331-334.
